Ajax-CECO CNC Hydraulic Solid Frame Die Forgers (SFDF)
The Ajax-CECO CNC Hydraulic Solid Frame Die Forger (SFDF) combines programmable hydraulic operation with PLC touch-screen controls for precise, repeatable blow-energy control. Available with a one-piece cast steel or 3-piece CECO frame design, the SFDF is engineered for demanding forging applications.
Request a Quote
View Specifications
Product Overview
Solid Frame Strength Meets Precision Hydraulic Control
This hydraulic die forger hammer uses stored hydraulic energy to deliver a controlled strike for closed-die forging. Available in multiple sizes and blow-energy capacities up to 118,000 ft/lbs, the SFDF can be configured to meet a range of application and production requirements. As part of the Ajax/CECO/Erie
Press programmable hammer lineup, SFDF models offer programmable control for demanding forging applications.
Built From Cast Steel or Classic Ceco Design
Each SFDF frame is a single U-shaped casting or a 3-piece Ceco design, built with extra-wide radial guides for lateral stability under impact.
Guide clearance and die capacity scale by size, so smaller units suit tight spaces and larger units handle wider dies.
- Guide clearance is 19.7 inches on the smallest size and 37.8 inches on the largest
- Guides secure at three mounting points to stop bolts from working loose under repeated strikes
- Maximum die width is 15 inches on the smallest size and nearly 32 inches on the largest
Request A Quote
Each SFDF frame is a single U-shaped casting or a 3-piece Ceco design, built with extra-wide radial guides for lateral stability under impact.
Guide clearance and die capacity scale by size, so smaller units suit tight spaces and larger units handle wider dies.
- Guide clearance is 19.7 inches on the smallest size and 37.8 inches on the largest
- Guides secure at three mounting points to stop bolts from working loose under repeated strikes
- Maximum die width is 15 inches on the smallest size and nearly 32 inches on the largest
Touch Screen Control Over Every Strike
Job setup and operating parameters can be managed through the SFDF touch-screen interface.
Siemens or Allen-Bradley control options support programmable operation and allow operators to enter pause or delay settings directly into the strike sequence.
Job setup and operating parameters can be managed through the SFDF touch-screen interface.
Siemens or Allen-Bradley control options support programmable operation and allow operators to enter pause or delay settings directly into the strike sequence.
CNC Hydraulic Die Forger Hammer Specifications
Every SFDF model breaks down by blow energy, stroke length, striking frequency, and total weight in the table below. Compare guide clearance and motor power side by side to match the right size to your die and production volume before requesting a custom quote.
| Model | Blow Energy | Guide Clearance | Stroke Min–Max | Max Strikes/Min | Max Die Width (in) | Ram Weight (lbs) | Total Weight (tons) | Motor Power (HP) |
| 11 SFDF | 11,801 | 19.7 | 19.5–24.8 | 95 | 15.0 | 2,535 | 28.7 | 40 |
| 18 SFDF | 18,439 | 24.0 | 20.5–26.8 | 90 | 19.3 | 3,968 | 46.3 | 74 |
| 23 SFDF | 23,233 | 26.0 | 22.0–28.3 | 90 | 21.3 | 4,960 | 57.3 | 74 |
| 36 SFDF | 36,878 | 30.3 | 22.0–28.3 | 85 | 25.6 | 7,716 | 90.4 | 147 |
| 46 SFDF | 46,467 | 32.7 | 25.2–31.5 | 80 | 28.0 | 9,590 | 114.6 | 147 |
| 59 SFDF | 59,005 | 35.0 | 24.8–34.6 | 80 | 29.9 | 12,346 | 135.6 | 242 |
| 73 SFDF | 73,756 | 37.8 | 23.6–33.5 | 75 | 31.9 | 15,432 | 172.0 | 242 |
| 92 SFDF | 92,195 | 37.8 | 27.6–37.4 | 70 | 31.9 | 18,960 | 215.0 | 300 |
| 118 SFDF | 118,009 | 37.8 | 31.5–39.4 | 65 | 31.9 | 21,605 | 264.6 | 355 |
Note: All specifications are nominal and subject to customization based on application requirements. Contact our engineering team for detailed specifications and custom configurations.
Engineering Made for Precision Production Runs
As a solid frame forging hammer manufacturer, Ajax/CECO/Erie Press builds each SFDF with an advanced taper blow valve, flexible compound oil cylinder and hammer rod, and a built-in hydraulic ram buffer. These engineered features support controlled operation and durability for demanding forging applications.
Our parts library keeps replacement components on hand.
Energy Efficiency That Protects Your Dies Too
This energy-efficient hydraulic forging hammer only draws full motor power while forging, not between parts, cutting electricity costs compared to air-driven hammers of similar capacity. That same fine energy control keeps blow force directed into the part rather than the frame and dies, extending die life and reducing demand on replacement parts.
Less wasted energy, less wasted tooling.
This energy-efficient hydraulic forging hammer only draws full motor power while forging, not between parts, cutting electricity costs compared to air-driven hammers of similar capacity. That same fine energy control keeps blow force directed into the part rather than the frame and dies, extending die life and reducing demand on replacement parts.
Less wasted energy, less wasted tooling.
The Right Hammer for Your Next Production Run
Ajax/CECO/Erie Press engineers work directly with customers to select the appropriate SFDF configuration based on application requirements, including blow energy, guide clearance, die size and control requirements.
Multiple SFDF sizes and configurations are available to support a range of forging applications and production requirements. Request a custom quote and put more than a century of forging engineering experience behind your next production run.
Request a Quote
Ajax/CECO/Erie Press engineers work directly with customers to select the appropriate SFDF configuration based on application requirements, including blow energy, guide clearance, die size and control requirements.
Multiple SFDF sizes and configurations are available to support a range of forging applications and production requirements. Request a custom quote and put more than a century of forging engineering experience behind your next production run.
CNC Hydraulic Solid Frame Die Forgers (SFDF) Manuals and Product Documentation
Download the complete Ajax-CECO CNC Hydraulic Solid Frame Die Forgers (SFDF) brochure for detailed specifications, dimensional drawings, and engineering data.
