Pneumatic Die KeyDriver
This pneumatic die key driver puts controlled, repeatable force behind every die key and sow block job on your floor. Forge shops depend on it to keep changeovers fast and operators safe.
Request a Quote
View Specifications
Product Overview
The Pneumatic Die KeyDriver Built to Replace Your Sledgehammer
The ERIE KeyDriver is a horizontal pneumatic hammer that drives die keys and seats sow blocks without a single swing of a sledgehammer: the perfect addition to your workflow.
One Die Key Driving Machine for Every Sow Block Installation
Beyond installing dies, this die key driving machine also removes them, handling both directions of a die change with the same controlled force.
It replaces manual rams and small handheld pneumatic drivers used for sow block installation tool tasks and general tooling adjustments. Two cylinder bore sizes let the KeyDriver match tonnage needs across different forging presses, so one machine style fits crews doing frequent changeovers and infrequent press maintenance work alike.
Every stroke reaches full extension or retraction on command, keeping pace with production schedules.
Request A Quote
Beyond installing dies, this die key driving machine also removes them, handling both directions of a die change with the same controlled force.
It replaces manual rams and small handheld pneumatic drivers used for sow block installation tool tasks and general tooling adjustments. Two cylinder bore sizes let the KeyDriver match tonnage needs across different forging presses, so one machine style fits crews doing frequent changeovers and infrequent press maintenance work alike.
Every stroke reaches full extension or retraction on command, keeping pace with production schedules.
Forklift-Mounted Pneumatic Hammers and Their Precise Alignment
Forklift mounting turns the KeyDriver into a portable, forklift-mounted pneumatic hammer that operators can position at the exact height and angle a die key or sow block requires.
A hand-held lever valve controls each stroke remotely, with a spring-centered return that stops motion the instant the operator releases the handle. Large ported valves open and exhaust quickly, keeping response time tight even under repeated strokes.
Request a Quote
Forklift mounting turns the KeyDriver into a portable, forklift-mounted pneumatic hammer that operators can position at the exact height and angle a die key or sow block requires.
A hand-held lever valve controls each stroke remotely, with a spring-centered return that stops motion the instant the operator releases the handle. Large ported valves open and exhaust quickly, keeping response time tight even under repeated strokes.
Technical Specifications
Available in multiple capacities to suit your specific forging requirements
| Specification | KD-10 X 30 | KD-10 X 40 |
| Blow Energy (ft·lb @ 90 PSIG) | 3,840 | 6,600 |
| Blow Energy (kJoule) | 17.1 | 29.4 |
| Stroke | 30 in (76 cm) | 40 in (102 cm) |
| Cylinder Bore | 10 in (25 cm) | 10 in (25 cm) |
| Overall Length, Retracted | 69-1/4 in (176 cm) | 81 in (206 cm) |
| Overall Length, Extended | 99-1/4 in (252 cm) | 121 in (307 cm) |
| Body Length | 56-1/2 in (144 cm) | 66-1/2 in (169 cm) |
| Width | 42-1/2 in (108 cm) | 42-1/2 in (108 cm) |
| Overall Height | 46 in (117 cm) | 46 in (117 cm) |
| Height of Centerline | 8-1/2 in (22 cm) | 8-1/2 in (22 cm) |
| Ram Face (H x W) | 10 x 7 in (25 x 18 cm) | 10 x 7 in (25 x 18 cm) |
| Center of Gravity, Retracted | 26-3/8 in (67 cm) | 31 in (79 cm) |
| Center of Gravity, Extended | 30-3/8 in (77 cm) | 36 in (91 cm) |
| Forklift Openings | 7-1/2 in (19 cm) | 7-1/2 in (19 cm) |
| Weight | 4,525 lbs (2,053 kg) | 6,672 lbs (3,026 kg) |
Note: All specifications are nominal and subject to customization based on application requirements. Contact our engineering team for detailed specifications and custom configurations.
Key Details Behind Pneumatic Die KeyDrivers
Every part of the KeyDriver withstands constant impact work, not just occasional use. These are the components keeping it running strong shift after shift.
Forged Restraining Lugs
Keep the unit locked in position during operation so blows land exactly where they’re aimed.
Cast Iron Inertia Block
Absorbs recoil from every strike, protecting the frame and stabilizing the ram path.
Alloy Forged Steel Ram
Withstands the shock of repeated impact without deforming or losing striking force over time.
Composite Piston and Support Rings
Reduce internal wear so the cylinder holds pressure through years of daily strikes.
Bronze Ram Rod Bushing
Lets the ram travel with minimal friction, extending service life between rebuilds.
Throttled Return Speed
Regulates how fast the ram retracts, giving operators consistent control on every cycle.
Sow Block Driver Durability Built for the Toughest Forge Shop Conditions
Every KeyDriver ships backed by complete repair services, so shops invest once and keep the same unit running for years instead of replacing it at the first sign of wear. The added mass in the larger KD-10 X 40 absorbs more recoil per strike, reducing vibration transfer to the frame and cutting long-term fatigue on internal components.
Request a Quote
Every KeyDriver ships backed by complete repair services, so shops invest once and keep the same unit running for years instead of replacing it at the first sign of wear. The added mass in the larger KD-10 X 40 absorbs more recoil per strike, reducing vibration transfer to the frame and cutting long-term fatigue on internal components.
Die Key Installation Equipment Ready to Run From Day One
The KeyDriver arrives fully assembled and connects directly to your plant air supply, with no on-site staging needed before the first strike. An onboard regulator, lubricator, and filter manage air quality automatically, while condensation drains and shut-off valves handle routine upkeep without extra tooling.
Every unit includes an operations manual, and an optional spare parts package keeps common wear items on hand before they’re needed.
The KeyDriver arrives fully assembled and connects directly to your plant air supply, with no on-site staging needed before the first strike. An onboard regulator, lubricator, and filter manage air quality automatically, while condensation drains and shut-off valves handle routine upkeep without extra tooling.
Every unit includes an operations manual, and an optional spare parts package keeps common wear items on hand before they’re needed.
Manuals & Product Documentation
Download the full product brochure below.
Put the Right Pneumatic Die KeyDriver to Work in Your Forge Shop
Every shift without the right pneumatic die key driver costs more in strain, downtime, and inconsistent installs than the machine itself. Send us your tonnage and shift details, and our team will match you to the correct KeyDriver model and turn around a quote fast.
